12V 20A Lead-acid Battery Charger
Item No.: VL1220
Case mateiral: Aluminum
Input voltage: 110V or 230V
Rated output: 12V 20A
Max charging: 14.4V or 14.7V customized
Applied to battery types: 12V Lead-acid, AGM, GEL
Smart Charging: Pre-charge, CC, CV and Floating
Size: 170x 90 x 63 mm
Net weight: 1.5kg
Warranty: 2 years
- Product Details
12V 20A Smart Lead-acid / AGM Deep Cycle Battery Charger High Frequency For Lithium Or AGM Batteries
Brief Description:
12V 20A Lead-acid / AGM deep cycle battery charger 12 volts 20 amps, input with worldwide 110 to 230Vac and rated output voltatge is 12V 20A. Smart max charging voltage is 14.4 / 14.7V for SLA type batteries or AGM batteries. Intelligent 4 steps charging with pre-charge, CC, CV and floating steps, this charger will charge your battery powered electric vehicles (bicycles, motorcycles and scooters) very fast and safe (automatic lockout when charging), with high efficiency and pretect your battery life maximumly. High quality, factory price and 2 years warranty.
1) Optional charging methods: Lithium or AGM batteries.
2) Advanced high frequency switching mode power supply technology.
3) DC output isolated from AC input.
4) Automatic worldwide Input 110/230Vac(90~264Vac), 50Hz~60Hz.
5) Charging parameters are insensitive to the AC input line voltage variations.
6) Completely automatic 4 steps charge: pre-charge, CC, CV, floating/trickle or shut-off.
7) Protections: Short circuit, Over - voltage, Over - temperature, Reverse Polarity.
8) Aluminum casing, light weight, portable.
9) 100% full load burn-in test.
10) 2 years warranty.
Technical Specs.:
1) Dimensions(LxWxH): 170 x 90 x 63 mm
2) Net weight: 1.5 KG
3) Max charging voltage(CV): 14.4 / 14.7 volt
4) Floating voltage: customized
5) Max output current (CC): 20 amps
6) Charging method: pre-charge, CC, CV, floating / trickle or shut off
7) AC input voltage: 110 / 240Vac
8) AC input freq.: 50 / 60 Hz
9) AC plug: customized by user’s country
10) Output connector type: customized by applications
11) Enclosure: Aluminum
AC Input:
110 / 230V
Frequency:
47~63HZ
Q. What do the abbreviations MF, GEL and AGM mean?
Q. What do the abbreviations LiFePO4, Li-ion, Li-MnO2 and LiCoO2 mean?
A. LiFePO4, Li-ion, Li-MnO2 and LiCoO2 are abbreviations for different types of lithium batteries, that means there batteries using different cathode materials. Different batteries have different charging voltages.
Q. What charger should I choose?
Q. Can I charge several batteries in parallel?
Q. Can you really connect and then forget about the charger?
Features
Output series: 360W Size: 170×90×63 mm Net weight: 1.5 KG
Input
Model
Apply to battery types
Floating V
CV (V)
CC (A)
Switching
VL1220L
12V LiFePO4 Battery
14.6V
20A
CC5~8%
VL1220
12V Lead-acid Battery
13.5V
14.7V
20A
CC20%
VL2412LM
24V Li-MnO2 Battery
29.4V
12A
CC5~8%
VL2412L
24V LiFePO4 Battery
29.2V
12A
CC5~8%
VL2412
24V Lead-acid Battery
27.6V
29.4V
12A
CC20%
VL3608LM
36V Li-MnO2 Battery
42V
8A
CC5~8%
VL3608L
36V LiFePO4 Battery
43.8V
8A
CC5~8%
VL3608
36V Lead-acid Battery
41.4V
44.1V
8A
CC20%
VL4805LM
48V Li-MnO2 Battery
54.6V
5A
CC5~8%
VL4805L
48V LiFePO4 Battery
43.8V
5A
CC5~8%
VL4805
48V Lead-acid Battery
55.2V
58.8V
5A
CC20%
VL6004L
60V LiFePO4 Battery
73V
4A
CC5~8%
VL6004
60V Lead-acid Battery
67.5V
73.5V
4A
CC20%
VL7203L
72V LiFePO4 Battery
87.6V
3A
CC5~8%
VL7203
72V Lead-acid Battery
81V
88.2V
3A
CC20%
Note: customized input / output / plug type / connectors are available.
Battery Knowledge
A. Gel, AGM, Vlies, MF, Calcium/Calcium and Hybrid are abbreviations for different types of lead-acid batteries.
Battery Charger Knowledge
A. It depends on the type of battery, the capacity of the battery, the application and how much you are prepared to spend. Just tell us your battery information, DANL battery charger engineer will recommend the most suitable charger for you or customized by your batteries and applications.
A. The charger has no problem whatsoever of charging or maintaining several batteries, as long as they are connected in parallel. The charger sees the parallel connected batteries as one large battery. The sum of the capacity has to be below the recommendation for your model. Please note that there could be a high current between batteries when they are connected together, i.e. use high quality wiring.
A. That depends on your batteries state and charger’s type. Danl lead-acid battery chargers have maintenance mode(floating mode), charger charges with very small current at this mode, so you can forget about the charger but not exceed 24 hours. If your battery is lithium type and without BMS system, please don’t forget the charger.
12V 20A Lead-acid Battery Charger For Your E-Life
No matter the romantic cycling city Copenhagen of Denmark, the passionate motorcycle home of America or the congested city of Beijing, the modes of transportation must be the best way to show the city life style.
With the development of society, electric vehicles are not only a vehicle but a life style of simple, convenient, economic and environmental protection.
As a relevant and important part of battery, a high quality battery charger will help you save money and Time.
VLDL 12V 20A Lead-acid Battery Charger in 360W output power is a good choice for your E-vehicles. There are different advantages related in the 12V 20A battery charger. It is an awesome arrangement for the individuals who require the better charge in the battery. Presently, the general population can purchase various types of battery charger from the trustworthy organization.
Smart power system Prolong the battery life. Once the battery is full, the charger screens the battery voltage discontinuously. As lead-acid battery need the longer charging time than lithium battery , it can protect the circuit inside the car effectively.
There are thousands of battery charger brand in the market , fine a reliable manufacturer is also a important thing to save your time and improve efficiency. You will realized that the regular battery charger may not suitable for your battery as it is tailor-made or your battery required especial power. So a manufacturer who can make the customization is necessary for you.
